150ml-2L 4 Cavity PET Blowing Machine

Name: 150ml2L 4 Cavity PET Blowing Machine
Brand: ECENG
Price: 1 USD

Quality 150ml-2L 4 Cavity PET Blowing Machine for sale

Place of Origin : Jiangsu, China

Brand Name : ECENG

Certification : ce sgs iso

Packaging Details : pet bottle blowing machine will be packed with wooden case for long time sea transport.

Supply Ability : 15 Set/Sets per Month drink bottle maker

MOQ : 1set

Payment Terms : L/C, T/T, Western Union

Delivery Time : 45days

Model Number : Q6000

Plastic Processed : PET

Bottle Volume(ml) : 2000 ml

Condition : New

Application : bottle

Blow Moulding Type : Stretch Blow Moulding

Voltage : cutomized

Dimension(L*W*H) : 3.4x1.6x1.9

Hollow part volume : 2l

Weight (KG) : 4500 KG

Automation : Automatic

Warranty : 1 Year

Key Selling Points : Automatic

Automatic : Yes

Cavity choice : 4

Volume choice : 150ml-2L

Output : 6000pcs/hr

Production Capacity (BPH) : 6000 BPH

Port : FOB Shanghai

Contact Now

6000BPH pure water beverage bottle making production machine line for plastic bottle

specification

Model		Q6000
Bottle type specification	Cavity	4
	Max.volume	2L
	Bottle mouth maximum overall diameter	28-38mm
	Bottle biggest diameter	105mm
	Bottle maximum height	330mm
Production specification	Theoretical output	6000BPH
	Bottle type capacity	500ML
	Bottle type weight	17g
	Bottle type	circular
Power specification	Light tube quantity	32pcs
	Light tube power	1.5KW
	Maximum heating power	48KW
	All electric machine installation	52KW
	Actual consumption	40%--70%
Air pressure specification	Work pressure	7-9kg/cm2
	Low-pressure gas consumption	1000L/min
	Blow bottle pressure	25-35kg/cm2
	Higher -pressure gas consumption	3000Ltr/min
Air pressure specification	Work pressure	5-6 kg/cm2
	Temperature range	10℃
	Consumption	8000kcal/hr
	Forzen water flow	138L/min
Machine specification	Machine size	4.2x1.6x1.9
Machine specification	Machine weight	4.5ton

Q series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 2 cavity to 9 cavity with a speed of 1000 bottles per hour (500 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.

Our Advantage

1. Resonable price 2. Good after service 3. experienced skilled workers and professional engineers 4. Good quality ,excellent service ,long life mould 5. on time delivery time

Want to know more message , contact us with out hesitate ! Inquiry us now !

Detailed Images

Q linear bottle blowing machine adopts advanced microcomputer PLC control system, stable performance,manual type and fully automatic type. Q series linear bottle blowing machine features: 1.stable and accurate running at high speed,adopt more stable and advanced microcomputer PLC control system. 2. production process is fully automated, with the advantages of low investment, high efficiency, easy operation, simple maintenance and safety. 3. suitable for flexible production of quantity and various bottle shape,wide range of applications,meet customer needs. 4. manual and automatic methods of operation, human-machine interface control, simple operation. 5. servo transmission system, high positioning accuracy, fast speed stability and good reliability. 6. less than 0.2% scrap rate for finished bottle .

After Sales Service

1. Installation, debug We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing capacity of the line. 2. Training Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures. 3.the sample service 1'We can send you the video of the running machine. 2'You are welcome to come to visit our factory,and see the machine running. 4.We can design the machines according your requirements,at the same time we will give you our professional suggestion,as you know,we have been in this industry for 12 years. 5.We provide one year warranty 6.well-trained & experienced staff are to answer all your inquiries in English and Chinese 7 .12 Months guarantee and life-long technical support. 8.Your business relationship with us will be confidential to any third party. 9. Good after-sale service offered, please get back to us if you got any questions.

FAQ

Q:Your company is a trading company or a direct factory?

A:We are a direct factory which locates in Zhangjiagang city.

Q:All of your products are made by yourself or compacted via purchasing the others?

A:We have independent technical team who focus on making machines,all the products are made by our technical team.

Q:What is the ability of your factory?

A:About 80 lines per year.

Q:Do you have any other services about your products?

A:We have a lot of experience on making projects and specifications for our clients,also we have a fixed service system.

Q:How do you make the quotation for clients?

A:The price depends on quality and performance but the clients should be satisfied first.
